Description

Boat part number 7104047 is a new MOMENTARY ON/OFF/MOMENTARY ON trim rocker switch from Carling, part number 201577 . Commonly used on Ranger boats, but may be used on other boats.

This trim rocker switch is constructed out of black plastic, and measures approximately 2″ L x 1 1/8″ W x 2″ D overall. Requires an approximate 1 1/2″ L x 7/8″ W x 1 1/2″ D cutout. Rated For 12 volts and 20 amps. Uses (6) male spade connections. Prelabelled with “TRIM” and icon.

Specifications:

• Boat Manufacturer: Ranger Boats
• Part Manufacturer: Carling Technologies
• Part Number: 201577
• Position: MOMENTARY ON/OFF/MOMENTARY ON
• Material: Plastic
• Color: Black
• Finish: Matte
• Electrical: 12V | 20A
• Overall Dimensions: 2″ L x 1 1/8″ W x 2″ D
• Cutout:1 1/2″ L x 7/8″ W x 1 1/2″ D
• Connections: (6) Male Spade
